186 Driving and operation
Picture no: 18394s.tif
Green marking on the rotary lever is visible.
Lock coupling ball bar and remove key.
Check that the coupling ball bar is correctly
installed
z Green marking on the rotary lever is
visible.
z There must be no gap between the
rotary handle and the coupling ball bar.
z The coupling ball bar must be firmly
engaged in the opening.
z The coupling ball bar must be locked
and the key removed.
Picture no: 18397s.tif
Eye for break-away stopping cable
In the case of trailers/caravans with brakes,
attach breakaway stopping cable to eye.
9 Warning
Towing a caravan/trailer is only per-
mitted with a properly fitted coupling
ball bar. If the coupling ball bar cannot
be correctly fitted, please contact a
workshop for assistance.
