202 Self-help, vehicle care
Picture no: 18316s.tif
3. The jacking points are marked.
With versions of the Corsa OPC with sill
panelling 3 or retrofitted sill panelling 3
no jack 3 must be used. The vehicle may
be damaged.
Picture no: 18429s.tif
4. Before attaching the jack 3, set it to the
required height. Fit the jack arm at the
front – or rear – in such a way that the
jack claw (arrow in figure) goes around
the vertical ridge and engages in the
recess in the ridge. Ensure that the claw
is properly positioned.
Picture no: 18430s.tif
The edge of the jack base must be
planted firmly and vertically in line with
the contact point.
Raise vehicle by turning crank handle.
If this is not the case, carefully lower the
vehicle immediately and reposition the
jack.
