55Seats, Interior
Picture no: 18279s.tif
5-door passenger vehicle
Lift the cover backwards as shown in the
illustration, until it unlatches, then remove.
Fit in reverse order.
Picture no: 18414s.tif
3-door passenger vehicle
Lift the cover backwards as shown in
figure 18414 S, until it unlatches, set at
an angle, then remove.
Fit in reverse order.
Picture no: 18415s.tif
Stowing
When the luggage compartment is fully
loaded, stow the luggage compartment
cover behind the rear seat backrests:
Lift the cover backwards as shown in
figure 18415 S, until it unlatches, then slide
down in guides behind the seat backrests.
