74 Seats, Interior
The curtain airbag system will not be
deployed in the event of
z the ignition is switched off,
z frontal collisions,
z accidents in which the vehicle overturns,
z collisions involving a rear impact,
z side-on collisions outside the passenger
cell.
Picture no: 18247s.tif
Control indicator v for airbag systems
The functionality of the airbag systems is
monitored electronically together with the
belt tensioners and displayed via the
control indicator v. When the ignition is
switched on, the control indicator comes on
for approx. 4 seconds. If it does not, or if it
does not go out after 4 seconds, or if it
comes on while driving, there is a fault in
the airbag systems or belt tensioners, see
also page 3 61. The systems might not be
deployed in the event of an accident.
Picture no: 18295s.tif
In the event of a fault in the airbag
systems, the LEDs flash in the button * for
switching off the airbag systems 3, the
control indicator * also illuminates.
Deployed airbags are indicated by
continuous illumination of v.
The system’s integrated self-diagnostics
allows faults to be quickly remedied.
9 Warning
Keep the area in which the airbag
inflates clear of obstructions.
9 Warning
Have the cause of the fault remedied
immediately by a workshop.
