OpenVox WGW1002 - Advanced Call Routing Rules; Routing Options Definitions

WGW1002 User Manual
OpenVox Communication Co.Ltd
29
NAT Settings
Table 4-2-2 Definition of NAT Settings Options
Options
Definition
Local Network
Format:192.168.0.0/255.255.0.0 or 172.16.0.0./12. A list of IP address or
IP ranges which are located inside a NATed network.
This gateway will replace the internal IP address in SIP and SDP messages
with the external IP address when a NAT exists between the gateway and
other endpoints.
Local Network List
Local IP address list that you added.
Subscribe Network
Change Event
Through the use of the test_stun_monitor module, the gateway has the
ability to detect when the perceived external network address has
changed. When the stun_monitor is installed and configured, chan_sip will
renew all outbound registrations when the monitor detects any sort of
network change has occurred. By default this option is enabled, but only
takes effect once res_stun_monitor is configured. If res_stun_monitor is
enabled and you wish to not generate all outbound registrations on a
network change, use the option below to disable this feature.
Match External
Address Locally
Only substitute the externaddr or externhost setting if it matches.
Dynamic Exclude
Static
Disallow all dynamic hosts from registering as any IP address
used for statically defined hosts. This helps avoid the configuration error
of allowing your users to register at the same address as a SIP provider.
Externally
Mapped TCP Port
The externally mapped TCP port, when the gateway is behind a static NAT
or PAT.
External Address
The external address (and optional TCP port) of the NAT.
External
Hostname
The external hostname (and optional TCP port) of the NAT.
