Opex DS2200 - Controls and Components

Operating the System 19
DS2200 User Manual - OPEX Corporation use only - not for distribution
Controls and Components
Figure 1: Main components
Conveyor
Sort trays
MICR reader,
audit trail printers
CIS imagers and
Data ports/connections (not shown)
See page 22 for
more detail
OpAssist
sensor
Described in detail on page 47
Feed mode knob
are located inside the scanner
