60 Operation
Falcon+ Operator Manual
OPEX Corporation
4.2.5.12. Preview Window/Image Viewer Window
The Preview pane provides a large image of a scanned item. View an image in
the Preview pane by selecting its thumbnail. Touch the image in the Preview
pane to open the Image Viewer in full-screen mode, where you can enlarge or
reduce the image, and scroll through and examine all images in a batch, one at
a time (see Figure 4-26). At the Manager level, the Preview window can be
moved and resized using built-in customization features.
Figure 4-26: Preview Window/Image Viewer Window
2. Click on or touch the
image to open it in the
Image Viewer window.
1. Select a Thumbnail.
The selected image appears
in the Preview window.
Use arrow buttons
to scroll through
the batch.
Select image of
page type you want
to view.
To Next Page
