Optek AF45 - Installation Material; High Voltage Power Supply (HVPS); Validation Filter

Maintenance
- 41 -
optek-Manual--1004-2003-02--AF45-US-2011-01-04
www.optek.com
9.8.7 Installation material
9.8.8 High voltage power supply (HVPS)
9.8.9 Validation filter
Tab. 27 Accessories - validation filter for VB option
When ordering a reference filter, the serial number (SN) of the sensor has to be
indicated.
Tab. 25 Spare parts — installation material
New part number
set Klüberpaste UH1 96-402 4 x 12 g 1201-3131-0002-00
Tab. 26 Spare parts - high voltage power supply
New part number
HVPS for AF45 1414-3139-4001-00
Absorption Old part number New part number
UV-filter 0.45 CU 3000-3211-00 1442-0015-0002-13
UV-filter 0.9 CU 3000-3212-00 1442-0015-0002-23
UV-filter 1.8 CU 3000-3213-00 1442-0015-0002-33
