4 Technical data and exploded views
Tab. 1 Technical data AS56-N and AS56-F
AS56-N AS56-F
Materials wetted: stainless steel 1.4435 (SS 316 L)
surface: electro-polished Ra < 0.8 μm
windows: sapphire (seal-less)
housing stainless steel 1.4571 (SS 316 Ti)
Port connection thread G 1-1/4", ISO 228/1
for port AS25 (similar to Ingold port)
diameter: 25 mm (0.98"), (D = 25 H7)
O-Ring groove for 30 mm and for 60 mm (1.18" and 2.36") port length
Port gasket O-Ring 18.64 x 3.53 mm (0.73" x 0.14") EPDM (FDA, USP Class VI)
Maximum insertion depth 35 mm (1.38") + OPL at a port length of 60 mm (2.36")
Optical path length (OPL) 5 or 10 mm
Pressure rating PN10 (test pressure PT 15 bar)
Admissible pressure PS 10 mbar - 10 bar for TS 0 °C / +90 °C (+32 °F / +194 °F)
Admissible pressure at
increased temperature
TS [°C] < 90 (194 °F)
100 (212 °F)
PS [bar] 10 8
Admissible process
temperature TS
permanent: 0–90 °C (32–194 °F)
peak (60 min/day): 0–100 °C (32–212 °F)
Ambient temperature operation: 0–40 °C (32–104 °F)
transport: -20–70 °C (-4–158 °F)
Airpurge connection M5: standard
Light source incandescent tungsten lamp: 5.0 V DC, 450 mA
Wavelengths 730 to 970 nm 430 nm
Detector silicon photodiode, hermetically sealed
Measuring range C4000:
any range between 0–0.05 to 4.0 CU
156:
0–0.5 to 4.0 CU
C4000:
any range between 0–0.05 to 1.5 CU
156:
0–0.5 to 1.5 CU
Cable connection with stainless steel connector, length:
2, 3, 5, 10, 15, 20, ... 45 or 50 m
(7, 10, 16, 33, 49, 66, ...148 or 164 ft.)
Cable material non-metallic sheathed cable with finely stranded copper conductor according to IEC 228
CL.5,
insulation PVC (-40 °C ... + 70 °C; -40 °F ... +158 °F)
Weight probe: approx. 2.0 - 2.5 kg, depending on model
cable set: approx. 1.5 kg/10 m
Protection all optical parts protected according to IP65 if sensor is constructed as intended, valid for
installation of plug or protection cap
Certificates ISO 9001:2000, PED, CE, HP0
