Technical data and exploded views
- 11 -
optek-sensors AS56, Version 04.2010_1.2US, 15.04.2010
www.optek.com
Note!
After welding, distortion has to be corrected at port AS25-GS60!
Modify the interior drill hole of
∅ 24.7 mm to obtain the nominal diameter ∅ 25 H7
(
∅ 25.0 - ∅ 25.032 mm) before installing the probe!
