11. Technical specification
CPU
Processor: STi7105* or STi7111
Flash memory: 8 MB
RAM memory: 256 MB
Satellite tuner / lnb
Input Connector: F-type, IEC 169-24
IF Input Frequency: 950MHz to 2150MHz
IF Loop Throughout
Input Level: -65 dBm~-25 dBm
LNB Power: 13 /18VDC / 500mA Max
DiSEqC Control: Unicable, 1.0, 1.2 & USALS compatible
Band Switch: 22KHz Tone(22 +/- 4KHz,Amplitude :0.6 +/- 0.2V)
Modulation method: LDPC/BCH(DVB-S2) 8PSK/QPSK, DVB-S QPSK
Symbol Rate: LDPC/BCH(DVB-S2) 8PSK/QPSK :10~30Msps
DVB-S QPSK : 1~45Msps
Decoding Rate 1/2 ,2/3 , 3/4, 5/6 a n d 7/8
Bandwidth: 36MHz
LDPC/BCH: Pun c t u r e d C o d e , 1/2 , 2/3 , 3/4, 3/5 , 4/5 , 5/6, 8/9 , 9 /1 0 i n D V B -S2
Terrestrial Tuner (optional**)
Input Frequency: 174-230, 470-862MHz (VHF i UHF)
Band: 7 or 8MHz
Input Level: -75 to -20dBm
Input Connector: IEC 169－2, Female
Input Impedance: 75Ω
MPEG transport Stream A/V Decoding
Demultiplex According to ISO/IEC 13818-1(MPEG-2 system)
Input stream Max. 90Mbit/s
Aspect Ratio 4:3(default), 16:9 letterbox
Video Decoding ISO/IEC 13818-2(MPEG2 video) MP@HL,
ISO/IEC 14496-10 HP@L4
Video Resolution 576p,720p or 1080i, 1080p
Audio Decoding ISO/IEC13818-3(MPEG2 audio/MUSICAM), AC-3
Audio Mode Single Channel / Dual Channel, Stereo, Joint Stereo
Front PCB
Display VFD or 7-Segment LED
Common Interface 1 (optionally 2)
Smartcard Reader 1 (optionally 2)
USB USB host (optional*)
Rear panel
RCA Video, Audio L, Audio R, YPbPr (optional*)
SCART TV (optional*)
S/PDIF Optical (optional Coaxial*)
HDMI 1.2
USB, IR Connector for external IR Sensor, RS232, Ethernet
Power supply
Input Voltage Free Voltage (100~250V AC, 50/60Hz) – version with internal power supply
DC 12V, 3A – version with external power supply
Power Consumption 17 W max.
< 1W in standby mode
Physical specification
Size[W*D*H] 280mm x 260mm x 60mm* or
195mm x 135mm x 40mm
Net Weight < 1.70 kg* or
< 1.50 kg
Operation Temperature 5℃~+45℃
Storage Temperature -10℃~+70℃
Storage Humidity 5%~95% RH (Non-Condensing)
* - Applies to HD 9600 Prima receiver
** - Applies to HD TS 9600 Prima receiver
Weight and dimensions are not absolutely exact values.
Specifications are subject to change (by manufacturer) without notice.
