Assembly
OPTIMUM
MASCHINEN - GERMANY
30 / 11 / 2007Page 30 Assembly Add-on kit D240/D280 ; Version 1.3.3
© 2007
GB
£ Open the terminal box on the spin-
dle head.
CAUTION!
Live parts.
Disconnect the machine.
Illustr.: 4-63: Open terminal block
£ In order to determine the position of
the new holes of the splash board,
apply the splash board in a way that
you can move the lathe saddle in
any direction without touching the
splash board.
Illustr.: 4-64: Holes in the terminal block
£ Remove the old angle brackets on
the splash board and produce new
angle brackets.
Illustr.: 4-65: New angle bracket
Fastening screws
Terminal block on the
spindle head
Holes in the terminal
block
Splash board
New angle bracket
Splash board
