Technical specification
Version 1.0.2 - 2020-07-07 13Translation of original instructions
DP26 EN
DP26_GB.fm
2.1 Emissions
CAUTION!
The operator should wear noise and hearing protection.
The A-weighted sound pressure level L
pA
is 70 to 73 dB.
The A-weighted sound power level L
WA
is 80 to 85 dB.
INFORMATION
This numerical value was measured on a new machine under the operating conditions specified
by the manufacturer. The noise behaviour of the machine might change depending on the age
and wear of the machine.
Furthermore, the noise emission also depends on production engineering factors, e.g. speed,
material and clamping conditions.
INFORMATION
The specified numerical value represents the emission level and does not necessarily a safe
working level. Though there is a dependency between the degree of the noise emission and the
degree of the noise disturbance it is not possible to use it reliably to determine if further precau-
tion measures are required or not. The following factors influence the actual degree of the noise
exposure of the operator:
Characteristics of the working area, e.g. size or damping behaviour,
other noise sources, e.g. the number of machines,
other processes taking place in proximity and the period of time, during which the operator
is exposed to the noise.
Spindle seat
MT 3
Drill table T-slot thread size
M12
T-slot size
12mm diagonally running
Table size
309 x 309 mm
Spindle stroke
95 mm
Throat depth
209 mm
Column diameter
Ø 80 mm
Distance spindle - drill table
max. 400 mm max. 770 mm
Distance spindle - base
max. 592 mm max. 1300 mm
Drilling table swivelling / rotating
± 45° / 360°
Dimensions
 "DP26 bench drill
dimension“ on page 14
 "DP26 column drill
dimension“ on page 15
Weight of the machine
96 kg 105 kg
Spindle speeds
 "Speed table“ on page 25
Speed steps
12
Ambient conditions Temperature
5 ~ 35 °C
Relative humidity
25 - 80 %
