PREPARATION
Note:
Complete all other connections
before connecting the system to AC
power and turning it on.
CONNECTING THE
SPEAKERS
1. Lift open the red and black
tabs for the right
(
R
)
and left
(
L
)
speaker terminals on the back of
the system.
2. Put the stripped end of the right
speaker’s striped wire into the
R
red terminal, then press the tab
until it clicks back into place.
3. Put the other right speaker’s wire
into the
R
black terminal, then
press the tab until it clicks back
into place.
4. Repeat Steps 2 and 3 to connect
the left speaker’s wires to the
L
and terminals.
CONNECTING THE AM
LOOP ANTENNA
Attach the supplied AM loop antenna
to the
AM ANT.
terminal on the back of
the system.
Attach the antenna stand and set the
antenna on a flat surface.
CONNECTING THE FM
ANTENNA
Press the
FM ANTENNA
terminal tabs,
put the stripped end of the supplied
FM antenna wires into the antenna
terminals on the back of the system,
then release the tabs.
+
-
illustration
+
-
+
-
illustration
illustration
illustration
