UP-67ETH, UP-127ETH,
UP-247ETH, UP-367ETH
Digital power unit
UP-x7ETH version 1.1
21
5.1.3. Activation of messages in the MP3 memory of the amplifier
Activation of the MP3 pre-recorded messages from the input/output contacts of the
amplifier.
9 messages can be activated.
Beforehand, it is necessary to configure this function by means of the
P.A. Manager software (SMP-250V2), so that a different message can
be assigned to each of the nine contacts (see section 6.2.3).
For their connection, refer to Figure 15.
Activation through the EMERGENCY IN connector.
This allows messages 1 and 2 to be activated.
To activate them, use contacts 4 and 5 of the RJ45 connector of the
emergency input, as described in Figure 4 in section 4.13.
Activation from the DC-600ETH / FC-600ETH desks.
Through the IP connection of the amplifier.
Activation from the P.A. Manager software.
5.2. Pre-recorded messages resident in the Flash memory of the
Coldfire circuit (WAV)
5.2.1. Characteristics
Access/Updating of messages
Remotely, by means of a PC, through the IP connection
Memory capacity
6 Mb
Maximum number of messages
3 messages (maximum size of 2 Mb/message)
File format
.WAV
Sampling rate: 48000 Hz, 24000 Hz and 12000 Hz (mono)
Sample size: 16 bits
The messages contained in the Coldfire flash memory are not available until a few seconds after the
amplifier has been turned on.
Figure 15
