10. TECHNICAL SPECIFICATIONS
UP-367TH
UP-247ETH
UP-127ETH
UP-67ETH
RMS power output
360 W
240 W
120 W
60 W
IHF power output
482 W
312 W
162 W
82 W
Total harmonic distortion
< 0.65 % (1 kHz)
< 0.5 % (1 kHz)
< 0.5 % (1 kHz)
< 0.5 % (1 kHz)
Bandwidth
50 ~ 18,000 Hz
(- 3 dB)
50 ~ 16,500 Hz
(- 3 dB)
50 ~ 17,000 Hz
(- 3 dB)
50 ~ 17,500 Hz
(- 3 dB)
Power unit signal/noise ratio
> 80 dB
> 83 dB
> 83 dB
> 83 dB
Control preamp signal/noise ratio
> 75 dB
> 75 dB
> 75 dB
> 75 dB
Inputs
1 program (0 dBu), 1 priority (0 dBu), 1 emergency (0 dBu), 2 Ethernet, MAIN IN, RS485
Analog input sensitivity
775 mV (program, priority, emergency and MAIN IN)
Loudspeaker line output
100 V, 70 V, 50 V / 4, 8, 16 ohms
Controls
Front program and priority volume,
rear Emergency and PRE OUT volume
Input/output contacts
9
Mains supply
230 V AC
Battery supply
24 V DC
Off-load consumption
41 VA
34.2 VA
32.5 VA
41 VA
Full load consumption
752 VA
485 VA
278 VA
163 VA
Fan activation
temperature
Front
Configurable
Configurable
Configurable
-
Rear
Configurable
Configurable
-
-
Overheating protection
95 °C
110 °C
110 °C
110 °C
Dimensions (mm)
482.6 (w) x 89 (h) x 368.5 (d)
Rack units
2
Weight
16.7 kg
14.7 kg
11 kg
9.6 kg
Finishes
Iron front panel painted RAL9005, iron cover painted black
