5.2.2. Transfer of messages to the Coldfire Flash memory
To transfer the WAV files to the flash memory, it is necessary to have a PC connected to the same IP
network as the amplifier and to use the Optimax Flasher application. This application is supplied
together with the P.A. Manager Software. To install it, run the file Optimax Flasher x.x.exe which can
be found in the folder 02_FIRMWARE of the installation CD and follow the instructions of the assistant.
Once the software has been installed, proceed as follows:
N.B.: The file transfer operations shown below are applicable from version 2.6.1 of the
Optimus Flasher software onwards.
1. Start the Optimax
Flasher application.
2. Select the Advanced
tab (1).
3. Enter the IP address of
the unit in the IP Host
field (2).
4. Select UP-ETH from the
Equipment Type drop-
down menu (3).
5. In the Update Options
section, tick the box
corresponding to the
message that you wish
to transfer (4) and
indicate the route and
file that you wish to use.
Repeat this operation
for each of the
messages that you wish
to update.
6. Press the button Start
Update Process (5) to
begin to transfer the
files.
7. Press OK when the process has been completed.
8. Exit the application (File > Quit).
5.2.3. Activation of messages in the Coldfire Flash memory of the amplifier
Activation from the input/output contacts of the amplifier.
3 messages can be activated.
Beforehand, it is necessary to configure this function by means of the
P.A. Manager software, so that a message can be assigned to each of
the first three contacts.
For their connection, refer to Figure 16.
Activation from the DC-600ETH / FC-600ETH desks, through the
ETHERNET connection of the amplifier.
Activation from the P.A. Manager Software (see section 8.5).
