UP-67ETH, UP-127ETH,
UP-247ETH, UP-367ETH
Digital power unit
UP-x7ETH version 1.1
46
ATTENTION
If the IP is activated by software, the functionality of IP address selection by DIP switches will be deactivated.
Once the change has been made, it can be undone by deleting the IP software via the web, or by selecting the address 0.0.0.0
on the DIP switches and restarting the unit.
ATTENTION
Once the IP address of the unit has been changed, it is necessary to modify this in the P.A. Manager software as well (see
section 6.2.1) and send configurations to the unit (see section 6.5).
2. Open the Expert menu (3) and click on the Set
IP address option (4).
3. Write the new IP in the IP Address
field (5) (for example: 10.1.1.100)
and click on Save IP Address (6).
(3)
(4)
(5)
(6)
