Optoma EX556 - 3 D Functionality Test

Condential
4-8
EX556/ES556/EW556/ES555/EX555
4-3-7 3D Test
Procedure - Test equipment: 1. DVD Player & PS3 &HQFS format CD
or 2. PC with 3D Graphic card
- Test signal: 1080p�24Hz�24Hz(for 3D movie)
720p�60HZ(for 3D game)
Inspection item - 3D test
Inspection Distance - 3~5 M
Criteria - The image should not appear noise, icker shadow, shocking,
abnormal color.
Inspection Distance - 1.4M ~1.6M
Criteria - Check any abnormal color, line distortion or any noise on the screen.
4-3-5 HDMI Port Test
Procedure - Test equipment: DVD Player with HDMI output.
- Test signal: 720p, 1080p, 1080i
Inspection item - HDMI performance test.
Inspection Distance - 1.4 M ~1.6M.
Criteria - Ensure the image is well performed and the
color can not discolor.
- Check whether "mute" is normal.
4-3-6 HDMI Port Test(3D)
Procedure - Test equipment: Blu - ray DVD with HDMI output.
- Test signal: 720p, 1080p, 1080i
Inspection item - HDMI 3D test.
Criteria - Connect DVD HDMI port and HDMI1 port of 3D box with HDMI cable,
connect HDMI out port of 3D box and projector HDMI port with HDMI
cable.
- The image should has 3D effect, not appear noise, icker shadow,
shocking,abnormal color.
