Optoma EX556 - Table of Contents

Condential
EX556/ES556/EW556/ES555/EX555
III
Table of Content
Chapter 1 Introduction
Highlight 1-1
Compatible Mode 1-2
Chapter 2 Disassembly Process
Equipment Needed & Product Overview 2-1
Disassemble Lamp Module 2-2
Disassemble Focus Ring 2-3
Disassemble Lamp Cover 2-4
Disassemble Main Board 2-5
ROD Adjustment 2-8
Re-write Lamp Hours 2-9
Chapter 3 Troubleshooting
LED Lighting Message 3-1
Main Procedure 3-2
Chapter 4 Function Test & Alignment Procedure
Test Equipment Needed 4-1
Test Condition 4-1
S-Video and Audion Port Test(not for ES555) 4-7
Video port Test 4-7
Component port Test 4-7
HDMI Port Test 4-8
HDMI Port Test(3D Test ) 4-8
3D Test 4-8
Run In Test 4-9
