Optoma EX556 - Page 48

EX556/ES556/EW556/ES555/EX555
Condential 6
Item PN Description
Parts
Supply
1 52.8CP01G001 DMD RUBBER X1161
48.8CQ01G003
0.55” XGA 2xLVDS SERIES 450 DMD -8 1076-603cB
TI
V
48.8EJ01G001
0.65’’ WXGA 2xLVDS SERIES 450 DMD -8 TI
1280-603cB
V
2 48.8EH01G001
0.55” SVGA 2xLVDS SERIES 450 DMD -8 TI
8060-603cB
V
3 80.8PJ02G001 PCBA DMD BOARD FOR G1.5 [PROJECTOR] V
4
52.8CP04G001
S450 0.55” XGA/SVGA DMD thermal pad, FUJIPOLY,
Sarcon XR-HE, 18.4x12.5x0.5 mm
5 61.8CP02H102 DMD HEATSINK YC AL-ALLOY Z15 X1161
6 61.8CP15H001 SPRING FOR DMD STEP SCREW X1161
7 61.8CP16H001 STEP SCREW FOR DMD M2.6*16.2mm X1161
8 61.8JS09H001 ROD COVER AL5052 Z15 4220
9 61.8JB02G001 ROD SPRING FOR EX610ST
70.8PJ19GR01 ASSY ROD MODULE FOR 8PJ (SERVICE) V
70.8PM11GR01 ASSY ROD MODULE FOR 8PM (SERVICE) V
10 70.8PJ11G001 ASSY ROD MODULE ES556
11 70.8PJ12G001 ASSY COLOR WHEEL MODULE ES556
12 85.1A526G050 SCREW PAN MECH M2.6*5 Ni NYLOK
70.8PJ17GR01
ASSY OPTICAL ENGINE MODULE FOR
8PJ(SERVICE)
V
70.8PM09GR01
ASSY OPTICAL ENGINE MODULE FOR
8PM(SERVICE)
V
13 70.8LG08G001 ASSY ENGINE BASE MODULE ES521
14 70.8CP10G001 ASSY ENGINE BOTTOM COVER Z15
15 85.1A526G060 SCREW PAN MECH M2.6*6 Ni NYLOK
16 70.8FP08G001 ASSY RELAY MODULE M410HD
17 23.8AH20G011 YO CONDENSER 1 FOR A15W
18 61.8EF03G001 CONDENSER LIGHT STOP EX615
19 23.8AH20G012 YO CONDENSER 2 FOR A15W
20 52.8CP22G002 DMD PORON+MYLAR FOR Z15/X15Z ENGINE
