EX556/ES556/EW556/ES555/EX555
Condential 12
Item PN Description
Parts
Supply
1 85.1C123G080 SCREW ISO M3*8mm NI PH W/LW
2 85.1C224G051
SCREW PAN MECH M4*5 COLOR W/TOOTH
WASHER Cr3+
3 85.1A526G040 SCREW PAN MECH M2.6*4 Ni NYLOK
4 85.WA123G080 SCREW PAN TAP M3*8 Ni
5 61.8PC09G001 AC-INLET-PLATE SECC 0.8t GEN 1.5
6 75.8PJ06G001 ASSY BOTTOM COVER MODULE ES556 V
70.8PJ16GR01
ASSY PHILIPS LAMP DRIVER MODULE 190W
FOR 8PJ(SERVICE)
V
7 70.8PJ06G001 ASSY LAMP DRIVER MODULE ES556
8 75.8PC01G001
POWER SUPPLY, AD-254W, AC INLET,
180*50, DL, HS-C
V
9 49.8PJ01G011
SUNON MF75251V1-Q000-G99; 7525 axial
fan; ROHS2.0
V
10 49.8PJ02G001 SPEAKER 2W 4Ohm 90mm V
11 75.87U02G001
ASSY INTERRUPTER SWITCH P5260
L=280MM
V
