Installation
3D SY NC
Out 5 V
5V PW R
Out 6W
( )
( )
3D SY NC
Out 5 V
5V PW R
Out 6W
( )
( )
m o l e x
MOLEX
E62405SP
R
Connect to Computer/Notebook
Connecting the Projector
1
2 3
1....................................................................................................Power Cord
2..................................................................................................*HDMI Cable
3................................................................................................... *VGA Cable
4....................................................................................................*USB Cable
5................................................................................................*RS232 Cable
6................................................................................................ *12V DC Jack
7...........................................................................................*3D Emitter cable
Due to the 
difference in
applications for
each country,
some regions may
have different
accessories.
(*) Optional 
accessory
6
54
7
3D Glasses
+12V Output
