Optoma HD91 - RS232 Protocol Function List

57
English
Appendices
RS232 Protocol Function List
Baud Rate : 9600
Data Bits: 8
Parity: None
Stop Bits: 1
Flow Control : None
UART16550 FIFO: Disable
Projector Return (Pass): P
Projector Return (Fail): F
XX=00-99, projector's ID,
XX=00 is for all projectors
There is a <CR> after all ASCII commands.
0D is the HEX code for <CR> in ASCII code.
Optoma Data and HT Projectors HD91/HD90
Baud Rate 9600
Data Bits 8
Parity None
Stop Bits 1
Flow Control None
UART16550 FIFO Disable
~ X X X X X n CR
space variable carriage return
ASCII Pass Fail
Power On/Off n=1/n=0 & 2 ~XX00 n P F
Re-sync ~XX01 n P F
HDMI 1 n=1
~XX12 n P
VGA n=5
VGA Com
p
onent n=8
Video
n=10
Com
p
onent RCA
n=14
HDMI 2
n=15
Cinema n=1
~XX20 n P F
Film n=11
Bright n=2
Photo n=3
Reference n=4
User n=5
ISF Day n=7
ISF Night n=8
3D n=9
Brightness n= -50 - +50 ~XX21 n P F
Contrast n= -50 - +50 ~XX22 n P F
Sharpness n= 0 - +15 ~XX23 n P F
Tint n= -50 - +50 ~XX44 n P F
Color n= -50 - +50 ~XX45 n P F
Red Gain
n= -50 - +50
~XX24 n
Green Gain n= -50 - +50 ~XX25 n
Blue Gain n= -50 - +50 ~XX26 n
Red Bias n= -50 - +50 ~XX27 n
Green Bias n= -50 - +50 ~XX28 n
Blue Bias n= -50 - +50 ~XX29 n
Reset n=1 ~XX33 n
D50 n=1 ~XX210 n
D65 n=2 ~XX210 n
D75 n=4 ~XX210 n
D83 n=5 ~XX210 n
D93 n=6 ~XX210 n
Native n=7 ~XX210 n
Native n=1 ~XX211 n
Adobe n=6 ~XX211 n
DLP Cinema n=2 ~XX211 n
HDTV n=3 ~XX211 n
SMPT-C n=5 ~XX211 n
Red n=1 ~XX212 n
Green n=2 ~XX212 n
Blue n=3 ~XX212 n
Cyan n=4 ~XX212 n
Yellow n=5 ~XX212 n
Magenta n=6 ~XX212 n
x offset -50 ~ 50 n= -50 - +50 ~XX213 n
y offset -50 ~ 50 n= -50 - +50 ~XX214 n
Brightness -50 ~ 50 n= -50 - +50 ~XX217 n
Reset n=1 ~XX215 n
Film
n=1
~XX35 n P F
Curve Type
Film/Video/Graphics/1.8
/1.9/2.0/2.1/2.2/2.3/2.4/2.5/2.6
n=-5 - +6
~XX182 n
Offset
n=-5 - +5
~XX183 n
Reset n=1 ~XX206 n
Video
n=2
~XX35 n
Curve Type
Film/Video/Graphics/1.8
/1.9/2.0/2.1/2.2/2.3/2.4/2.5/2.6
n=-5 - +6
~XX184 n
Offset
n=-5 - +5
~XX185 n
Reset n=1 ~XX207 n
Graphics
n=3
~XX35 n
Curve Type
Film/Video/Graphics/1.8
/1.9/2.0/2.1/2.2/2.3/2.4/2.5/2.6
n=-5 - +6
~XX186 n
Offset
n=-5 - +5
~XX187 n
Reset n=1 ~XX208 n
Standard
n=4
~XX35 n
Curve Type
Film/Video/Graphics/1.8
/1.9/2.0/2.1/2.2/2.3/2.4/2.5/2.6
n=-5 - +6
~XX188 n
Offset
n=-5 - +5
~XX189 n
Reset n=1 ~XX209 n
Auto n=1
~XX37 n P F
RGB (0-255)* * RGB (0-255) supports when HDMI is detected n=2
RGB(16 - 235)* *RGB(16 - 235)supports when HDMI is detected n=4
YUV n=3
Noise Reduction
n= 0 - 10
~XX196 n P F
PureMotion
OFF
n=0
~XX190 n
LOW
n=1
~XX190 n
MED
n=2
~XX190 n
HIGH n=3 ~XX190 n
UltraDetai
l
OFF
n=0
~XX41 n
ON
n=1
~XX41 n
HD+
n=2
~XX41 n
PureColor
OFF
n=0
~XX42 n
1
n=1
~XX42 n
2
n=2
~XX42 n
3
n=3 ~XX42 n
4
n=4
~XX42 n
5
n=5
~XX42 n
PureEn
g
ine Demo
OFF
n=0
~XX197 n
H Split
n=1
PF
V Split
n=2
PF
Power
100%/95%/90%/85%/
80%/75%/70%/65%/
60%/50%
n=0/n=1/n=2/n=3/n=4
/n=5/n=6/n=7/n=8/n=9
~XX326 n P
F
DynamicBlack 1 n=1 P F
DynamicBlack 2 n=2 P F
DynamicBlack 3 n=3 P F
4:3
n=1
~XX60 n P F
16:9 n=2
LBX n=5
Native n=6
Auto235 n=8
Auto235_Subtitle n=11
SuperWide n=9
Edge masking n=0-5 ~XX61 n P F
~XX191 n
DISPLAY
Don't support when Anamorphic lens is fixed
Don't support when Anamorphic lens is motored or fixed
LED Brightness
Supportingit When Anamorphic lens is fixed or motor
Don't support when Anamorphic lens is motored or fixed
Projector ID Command ID
Function
Direct Source Commands
Color Space
Advanced
Color Gamut
PureEngine
CMS
Gamma
RGB Gain/Bias
Color Temperature
Display Mode
Format
Color Settings
