PK201 Condential II
Item P/N Description Parts Supply
1 70.8EN01GR01 ASSY TOP COVER MODULE PK201(SERVICE) V
2 42.0030BG001
FFC M/B TO KEYPAD BOARD IOP P=0.5 50mm
PK201
V
3 51.8EN03G001 TOP COVER MN3600HA PK201 V
4 51.8EN07G001 TOP DECORATION PLATE PMMA PK201
5 51.8EN08G001 KEY BUTTON P+R PK201 V
6 52.8EN05G001 AM IC THERMAL PAD GR-Hm V
7 52.8EN06G001 DDP IC THERMAL PAD GR-Hm V
8 52.8EN07G001 DRAM IC THERMAL PAD GR-Hm V
9 52.8EN08G001 FLASH IC THERMAL PAD GR-Hm V
10 52.8EN09G001 TOP ENG THERMAL PAD GR-Hm V
11 61.8EN01G001 TOP CU PLATE CI100 0.5 PK201
12 80.8EN03G001 PCBA KEYPADBD FOR SMD ASSY PK201 V
13 85.3A12AG030 SCREW CAP HEAD MECH M1.4*3.0
14 52.8EN11H001 8EN CR4305 FOR DMD FPC
