Optoma PK201 - Page 38

PK201 Condential III
Assy Bottom Cover Module
Item P/N Description
Parts Supply
70.8EN02GR01 ASSY BOTTOM COVER MODULE PK201(SERVICE) V
1 51.8BU12G001 BATTERT PULL TAPE PK-101
2 51.8EN01G001 8EN BOTTOM COVER MN3600HA PK201
3 51.8EN04G001 IR COVER GE-121R PK201 V
4 51.8EN06G001 SPEAKER HOLDER MN 3600HA PK201
5 51.8EN10G001 FOCUS GEAR PK201
7 52.8EN12G001 DMD THERMAL PAD GR-Hm V
8 52.8EN10G001 BOTTOM ENGINE THERMAL PAD GR-Hm V
9 61.8EN02G001 BOTTOM CU PLATE C1100 1.5T PK201
10 61.8EN04G001 BOTTOM CU PLATE 2 C1100 0.5T PK201
11 85.1A12AG070 SCREW CAPHEAD TAP M1.4*7 PK201
