optris CS series User Manual

13
Technical Data
For a usage of the CS for online maintenance applications (in electrical cabinets e.g.) the following
recommend settings are already included in the factory default setting (but not active):
OUT
At 3-state output the following settings are default:
Pre-alarm difference: 2 °C
No alarm level: 8 V
Pre-alarm level: 5 V
Alarm level: 0 V
Service voltage: 10 V
IN/ OUT
At Alarm output (open collector) the following settings are default:
Mode: normally closed
Temp code output: activated (for values above alarm level)
Range settings: 0 °C = 0 %/ 100 °C = 100 %
Vcc adjust
If activated the following settings are default:
Output voltage range: 0-10 V
