optris CS series - Serial Interface; Protocol

48
5.2.1 Serial Interface
Baud rate:
9,6...115,2 kBaud (adjustable on the unit or via software)
Data bits:
8
Parity:
none
Stop bits:
1
Flow control
off
5.2.2 Protocol
All sensors of the CTlaser series are using a binary protocol. Alternatively they can be switched to an
ASCII protocol. To get a fast communication the protocol has no additional overhead with CR, LR or ACK
bytes.
