Installation

3.2 Electrical Installation

Analog device (mV-output at OUT pin)

• Use shielded cables only. The sensor shield has to be grounded.

• The shield [black] on the CS is not connected to GND [brown].In any case it is

necessary to connect the shield to ground or GND (whichever works best)!

The output impedance must be ≥ 10 Ω.

Use a separate, stabilized power supply unit with an output voltage in the range of 5–

30 VDC which can supply 100 mA. The residual ripple should be max 200 mV.
