optris CS series - Other Accessories

32
Figure 13: A combination of the laminar air purge collar with the bottom section of the mounting fork allows an
adjustment in two axes. [Order No.: ACCTAPL+ACCTMG]
3.1.3 Other accessories
If the protective window is used, the transmission has to be set to 0.83. To change this value the
optional USB-Kit (including CompactConnect software) is necessary.
