Installation
Figure 11: Standard air purge collar; fits to the mounting bracket; hose connection: 3x5 mm [Order No.: ACCSAP]
Figure 12: Laminar air purge collar – the side air outlet prevents a cooling down of the object in short distances; hose
connection: 3x5 mm [Order No.: ACCTAPL]
