optris CS series User Manual

16
2.3 Electrical specifications
Used Pin
Function
OUT
IN/ OUT
x
Analog
0-5 V
1)
or 0-10 V
2)
/ scalable
x
Alarm
output voltage adjustable; N/O or N/C
x
Alarm
3-state alarm output (three voltage level for no alarm, pre-alarm,
alarm)
x
Analog
programmable open collector output [0-30 V DC/ 50 mA]
4)
x
Temp. Code
Temp. Code Output (open collector [0-30 V DC/ 50 mA]
4)
x
Input
programmable functions:
• external emissivity adjustment
• ambient temperature compensation
• triggered signal output and peak hold function
5)
x
x
Serial digital
3)
uni- (burst mode) or bidirectional
OUT t/c K
Analog
Thermocouple output type K; alternatively selectable to the mV
output (software necessary)
