optris CS series User Manual

30
Figure 10: Mounting bracket, adjustable in two axes [Order No.: ACCTAB]
3.1.2 Air purge collar
The lens must be kept clean at all times from dust, smoke, fumes and other contaminants in order to
avoid reading errors. These effects can be reduced by using an air purge collar.
• Use oil-free, technically clean air only.
• The needed amount of air (approx. 2...10 l/ min.) depends on the application and
the installation conditions on-site.
