Figure 16: USB adapter cable incl. terminal block and software CD [Order No.: ACCSUSBK]
3.1.4 Tilt assembly
With this mounting accessory a fine adjustment of the CS with an off-axis angle +/- 6.5° is possible.
Figure 17: Tilt assembly [Order No.: ACCTTAS]
