optris CS series User Manual

19
Technical Data
Temperature coefficient
3)
±0.05 K/ K or ±0.05 %/ K (whichever is greater)
Temperature resolution (NETD)
4)
0.1 K
Response time
25 ms (95 % Signal/ adjustable to 999 s via Software)
Warm-up time
10 min
Emissivity/ Gain
0,100...1,100 (adjustable via 0-10 VDC input or software)
Transmissivity
0,100...1,000 (adjustable via software)
Interface (optional)
USB programming interface
Signal processing
Average, Peak hold, Valley hold, Advanced peak hold with threshold and
hysteresis, Triggered signal output, Triggered peak hold function (adjustable via
software)
Software
optional (CompactConnect)
1)
at ambient temperature 23 ± 5 °C and object temperatures >0 °C
2)
Accuracy for thermocouple output: ±2.5°C or ±1%
3)
for ambient temperatures <18 °C and >28 °C
4)
at time constant ≥100 ms with smart averaging and an object temperature of 25 °C
