ST 6100 - HARDWARE GUIDE
Table 1: ST 61xx Models
Model Pins Configuration
ST 6100 10-pin side or bottom mount
Terminals are available in two configurations: bottom connector or side connector (see figures below)
Figure 2: ST 6100 with Side Connector
Figure 3: ST 6100 with Bottom Connector
1.2 Key Features and Benefits
The ST 6100 has the following key features and benefits:
l Designed to be used as a standalone or incorporated into a Solution Provider’s (SP) solution
l Built-in multi-GNSS receiver to calculate position, speed and heading with SP-preferred constellation
l Quick and easy installation reduces labor time and costs
T406, VERSION 01
10
© ORBCOMM PROPRIETARY
