Oregon Harvester - Page 74

Guide Bar
69 Mechanical Timber Harvesting Handbook
3/4" Pitch Guide Bar Mounts
T161
1
3
3
2
Drive sprocket
tooth count:
9, 10
Dimensions:

.447"
x 5.500"

.880" x
.568"

.531" x
2.281"
T168
1
1
2
2
Drive sprocket
tooth count:
9, 10
Dimensions:

.609"

.562"
T177
T
177
1
2
2
Drive sprocket
tooth count:
9, 10
Dimensions:

.625" x
3.25"

.306"
T190
1
2
2
Drive sprocket
tooth count:
9, 10
Dimensions:

.760" x
5.25"

.760"
