Page: 14 of 71
Figure 12 The Chain Fitted
Attach the front guard to
the two standing screws.
Using the appropriate
tools from your kit, attach
the supplied bolts to the
top of the screws and
ensure that there is a
finger tight fit. Also see
Figs 13 - 18, below for
more detail and
information.
Figure 13 Chain Bar Lug
Close up of the lug on the
cover that needs to be
lined up with the guide
bar hole
