Page: 15 of 71
Figure 14 Guide Bar Lug Screw
The screw on the front of
the cover that adjusts the
lug shown on Fig 13.
Figure 15 Guide Bar Hole
The hole on the guide bar
that the lug needs to be
lined up with.

Oregon SL-YD5200B Specifications

General

Brand	Oregon
Model	SL-YD5200B
Category	Chainsaw
Language	English
