ORGAPACK OR-T 55
– If the green LED ashes on the back, the
tool can be removed.
► Press tensioning lever (1) against the handle.
Then swing the tool away from the strapping
to the right at the rear (2).
► Carry out a visual sealing inspection (Section
5.2).
WARNING
Never lift packaged goods on the
strapping, risk of injury.
The strapping is designed in such a
way that it is only intended to secure
the packaged goods during transport,
storage etc.
5.2 Checking the seal
WARNING
Never transport or move packaged goods with improperly performed strapping /
weld sealing - serious injuries may result.
Perform sealing check after each strapping.
► Perform sealing check by visual inspection.
1 Good seal (the entire sealing area has been
cleanly welded, without excess material being
forced out sideways).
2 Poorly welded seal (weld not over entire
sealing area), welding time too short.
3 Poorly welded seal (excess material has
been forced out sideways), welding time too
long.
In the case of straps with poorly welded seals:
► Check the welding time setting (Section 4.3).
► Strapping with poorly welded seals must be performed again.
► Check strap type (Section 7).
► If good welding is not achieved, the tool must be checked by an authorized service center.

 
