INPUT CONNECTIONS AND CONTROLS
As shown if Fig. 2, and Fig. 3, the CO 230, CO 260 and CO 430 input connections contain LEFT
INPUT and RIGHT INPUT connectors, GAIN Control, and a POWER indicator.
x\\\\_ /////////.
Fig. 2. Front panel layout for 230 and 260 amplifiers.
x\\\\ /////////.
Fig. 3. Front panel layout for the 430 (4channe!) amplifier.
