Ormazabal cpg.0 - Cpg.0-V 24 Kv 630 a; Cpg.0-V 1250 a and 1600 A;Cpg.0-Pt; Cpg.0-Vl

IG-123-EN version 11; 23/07/2021
25
General instructions
cpg.0: GIS medium-voltage switchgear,
gas insulated, up to 40.5 kV,
in accordance with IEC Standard
Installation
6.6.1. cpg.0-v 24 kV 630 A
The xing points for circuit-breaker cubicles up to 630 A are
dened in Figure 6.10:
Figure 6.10. Fixing points
6.6.2. cpg.0-v 1250 A and 1600 A/cpg.0-pt/cpg.0-vl
The xing points for 1250 and 1600 A circuit-breaker
cubicles are dened in Figure 6.11:
Figure 6.11. Fixing points with side connection
