6.6.5. cpg.0-s
The xing points for disconnector cubicles are dened in
Figure 6.14:
Figure 6.14. Fixing points
6.6.6. cpg.0-f/cpg.0-fl
The xing points for fuse-protection cubicles are dened in
Figure 6.15:
Figure 6.15. Fixing points
