General instructions
cpg.0: GIS medium-voltage switchgear,
gas insulated, up to 40.5 kV,
in accordance with IEC Standard
General description
1.3. Main components
1
Busbar compartment
2
Gas tank
3
Gas pressure relief duct
4
Cable compartment
5
Control compartment
6
Driving mechanisms compartment
Figure 1.1. Main elements of cpg.0 cubicles
