IG-123-EN version 11; 23/07/2021
28
Installation General instructions
cpg.0: GIS medium-voltage switchgear,
gas insulated, up to 40.5 kV,
in accordance with IEC Standard
6.6.7. cpg.0-rb
The xing points for busbar riser cubicles are dened in
Figure 6.16.
Figure 6.16. Fixing points
