Ormazabal cpg.0 - Cpg.0-V 2500 a; Cpg.0-C

IG-123-EN version 11; 23/07/2021
26
Installation General instructions
cpg.0: GIS medium-voltage switchgear,
gas insulated, up to 40.5 kV,
in accordance with IEC Standard
6.6.3. cpg.0-v 2500 A
The xing points for 2500 A circuit-breaker cubicles are
dened in Figure 6.12:
Figure 6.12. Fixing points
6.6.4. cpg.0-c
The xing points for longitudinal coupling cubicles are
dened in Figure 6.13:
Figure 6.13. Fixing points
