General instructions
cpg.0: GIS medium-voltage switchgear,
gas insulated, up to 40.5 kV,
in accordance with IEC Standard
Installation
Continuation
Cubicle
model
Manu-
facturer
Connector
Connector
series
Nº
terminals
Terminal
conguration
Max. rated
current
connector
[A]
Total
connector
length
[mm]
Max. diameter
on insulation
admitted by
the connector
[mm]
cpg.0-v/s
24-36 kV
25 kA
630-1250 A
cpg.0-v/s
24-36 kV
25 kA
630-1250 A
unied base
cpg.0-vl
24-36 kV
25 kA
630-1250 A
Nexans
EUROMOLD
Screened
400TB
1 cable 400TB + CUP 800 255 37.5
2 cables
400TB + M440CP
+ 400TB + CUP
800 500 37.5
3 cables
400TB + M440CP +
400TB + M440CP +
400TB + CUP
800 745 37.5
1 cable + SA
400TB + 400PB-10SA
+ CUP
800 410 37.5
2 cables + SA
400TB + M440CP +
400TB + 400PB-10SA +
CUP
800 655 37.5
440TB
1 cable 440TB + CUP 1250 255 56
2 cables
440TB + M440CP
+ 440TB + CUP
1250 500 56
3 cables
440TB + M440CP +
440TB + M440CP +
440TB + CUP
1250 745 56
1 cable + SA
440TB + 400PB-10SA
+ CUP
1250 410 56
2 cables + SA
440TB + M440CP +
440TB + 400PB-10SA +
CUP
1250 655 56
480TB
1 cable 480TB + CUP 1250 185 40.5
2 cables 480TB + 804PB + CUP 1250 295 40.5
3 cables
480TB + 804PB
+ 804PB + CUP
1250 405 40.5
4 cables
480TB + 804PB + 804PB
+ 804PB + CUP
1250 515 40.5
5 cables
480TB + 804PB + 804PB
+ 804PB + 804PB + CUP
1250 625 40.5
1 cable + SA 480TB + 800SA + CUP 1250 290 40.5
2 cables + SA
480TB + 804PB
+ 800SA + CUP
1250 400 40.5
3 cables + SA
480TB + 804PB + 804PB
+ 800SA + CUP
1250 510 40.5
4 cables + SA
480TB + 804PB + 804PB
+ 804PB + 800SA + CUP
1250 620 40.5
484TB
1 cable 484TB + CUP 1250 185 56
2 cables 484TB + 804PB + CUP 1250 295 56
3 cables
484TB + 804PB
+ 804PB + CUP
1250 405 56
4 cables
484TB + 804PB + 804PB
+ 804PB + CUP
1250 515 56
5 cables
484TB + 804PB + 804PB
+ 804PB + 804PB + CUP
1250 625 56
1 cable + SA 484TB + 800SA + CUP 1250 290 56
2 cables + SA
484TB + 804PB
+ 800SA + CUP
1250 400 56
3 cables + SA
484TB + 804PB + 804PB
+ 800SA + CUP
1250 510 56
4 cables + SA
484TB + 804PB + 804PB
+ 804PB + 800SA + CUP
1250 620 56
Continued on next page
