Ormazabal cpg.0 User Manual

IG-123-EN version 11; 23/07/2021
33
General instructions
cpg.0: GIS medium-voltage switchgear,
gas insulated, up to 40.5 kV,
in accordance with IEC Standard
Installation
Continuation
Cubicle
model
Manu-
facturer
Connector
Connector
series
Nº
terminals
Terminal
conguration
Max. rated
current
connector
[A]
Total
connector
length
[mm]
Max. diameter
on insulation
admitted by
the connector
[mm]
cpg.0-v/s
24-36 kV
25 kA-31.5 kA
2000-2500 A
2 connection
bushings
Nexans
EUROMOLD
Screened
400TB
2 cables
400TB + CUP 800 255 37.5
400TB + CUP 800 255 37.5
3 cables
400TB + M440CP
+ 400TB + CUP
800 500 37.5
400TB + CUP 800 255 37.5
4 cables
400TB + M440CP
+ 400TB + CUP
800 500 37.5
400TB + M440CP
+ 400TB + CUP
800 500 37.5
2 cables + SA
400TB + 400PB-10SA
+ CUP
800 410 37.5
400TB + CUP 800 255 37.5
3 cables + SA
400TB + M440CP
+ 400TB + CUP
800 500 37.5
400TB + 400PB-10SA
+ CUP
800 410 37.5
440TB
2 cables
440TB + CUP 1250 255 56
440TB + CUP 1250 255 56
3 cables
440TB + M440CP
+ 440TB + CUP
1250 500 56
440TB + CUP 1250 255 56
4 cables
440TB + M440CP
+ 440TB + CUP
1250 500 56
440TB + M440CP
+ 440TB + CUP
1250 500 56
2 cables + SA
440TB + 400PB-10SA
+ CUP
1250 410 56
440TB + CUP 1250 255 56
3 cables + SA
440TB + M440CP
+ 440TB + CUP
1250 500 56
440TB + 400PB-10SA
+ CUP
1250 410 56
Continued on next page
