General instructions
cpg.0: GIS medium-voltage switchgear,
gas insulated, up to 40.5 kV,
in accordance with IEC Standard
Operations sequence
For standard cubicles:
• cpg.0-s up to 24 kV/1600 A/25 kV
When the disconnector and/or earthing switch are
motorised, they are tted with a "MOTORISED" or "MANUAL"
driving switch, meaning the type of operation to be carried
out should be selected rst.
1
Manual operation
2
Motorised operation
Figure 7.8. Driving switch detail
