Orolia EdgeSync User Manual

orolia.com EdgeSync Manual rev 1 | 39
Oscillator
RO
OCXO 4 hours or OCXO 8 hours
GNSS Receiver
RO
GNSS Receiver information
Timing Engine FW
Version
RO
Version of firmware that is running on the Orolia’s internal
Managed Clock Engine
Timing Engine FPGA
Version
RO
Version of FPGA that is running on the Orolia’s internal
Managed Clock Engine
MAC Address
RO
MAC address of port 1
Serial Number
RO
Serial number
System Up Time
RO
Time since last reboot
Software Upgrade
From Local File button
RW
Browser button to navigate through the Host PC where the
browser is running to select previously downloaded EdgeSync
software
Protocol pull-down
option
RW
Only SFTP option is supported. Note, the image file is expected
to be in the home directory on SFTP server
Server IP
RW
IPv4 address of SFTP server
SW Image Filename
RW
Software file to be used for the upgrade
Server Login
Username
RW
Login credentials for SFTP server
Server Password
RW
Login credentials for SFTP server
Start SW Upgrade
button
WO
Clicking the button initiates upgrade process
Clear button
WO
Click to clear the latest changes
Software Upgrade
Status
RO
Display bar to show the upgrade progress
System Logs
Download
WO
Download the EdgeSync MCE Event Log to the Host PC. The
log file is encrypted and is for Orolia use.
System Power
Reboot button
WO
Reboot the EdgeSync system
Shutdown button
WO
Shutdown of the EdgeSync in controlled and sequential steps
that will protect the EdgeSync memory storage. Using this
button is recommended prior to disconnecting physical power
to the EdgeSync.
Table 16 System Options
IMPORTANT NOTE ON SOFTWARE UPGRADE:
Stopping the Engine is recommended before doing the software upgrade
SNMP Tab
SNMP Tab – Provides SNMP (v2, v3) Management Server configuration.
